Installation Profile
Technical Data
Size: Ød=220 mm ; ØD=240 mm ; h=15 mm
Material: FKM+FKM with fabric, brown color
Pressure: ≤25MPa
Speed: ≤0.5m/s
Temperature: -20℃～+230℃
Medium: General petroleum-based hydraulic oil, water, emulsified type.
Applications: Standard cylinders, telescopic cylindersmachine tools, spindle seals.
Product Features
Compact rod seal suitable for standard housings according to ISO 5597
Easy installation with stable fitting performance
Excellent sealing capability, even at low pressure levels
Low friction design enabled by the fabric-reinforced sealing surface
Design Tips
For reliable performance, the seal must operate within the maximum gap dimensions shown in the table. If the gap on the non-pressure side is larger than the recommended values, a full-surface plastic back-up ring should be added behind the seal. This prevents extrusion and ensures long-term sealing efficiency.
| Profile | Max. Permissible Gap Dimension | Max. Permissible Gap Dimension |
| 16 MPa | 25 MPa | |
| ≤ 6 | 0.2 | 0.1 |
| > 6 ~ 10 | 0.2 | 0.1 |
| > 10 ~ 15 | 0.2 | 0.1 |
